PCB/Board Design
Our Board Design Services portfolio covers all the requirements of custom analog, digital and mixed-signal board design, layout, assembly, manufacture and test for a wide range of applications. We work with our Clients to ensure a smooth hand-off to volume production to preferred vendors. Our well documented process ensures error free execution, with constant checks at each and every milestone. Leverage our vast experience of delivering 400+ sub-designs. Whether it's a proof-of-concept, new chip reference design, existing product re-engineering, ASIC emulation platform or a product board, we have you covered.
Specification
Architecture
Test Plan / Debug Hooks
Test Automation Support
PCB Layout
Rigid / Flex / Rigid-Flex
Component Library Development
Upto 24 Layers Rigid
3 mil traces
Blind / Buried microvias
​Mixed Signal / Power
0.4mm pitch BGA geometries
Signal Integrity
Pre / Post-Layout SI Analysis
Stackup / Material Selection
Termination Strategy
Routing Guidelines Development
Noise Analysis
Crosstalk / Reflection Analysis
Interface (DDRx etc.) Timing Analysis
Worst-case Design / Timing Budget
Tool: Mentor Hyperlynx® SI
Interfaces / Technologies
Bus: USB, PCIe, SATA
Networking: Ethernet, XAUI, 10GbE
Peripherals: UART, I2C, SPI, I2S
AV: HDMI, SDI
NPI/Production Support
DFM / DFA Analysis Support
Engineering Prototyping
Handoff to Production Partner(s)
NPI Build Support
Handling TQ/EQ from Partner(s)
Schematic Design
Component Selection
Schematic Capture
BOM Analysis
BOM Optimization
Tool Flows Available
Cadence® OrCAD™ / Allegro
Altium™
Mentor ® Xpedition® Enterprise
Mentor® Hyperlynx®
Power Integrity
IR/DC Drop Analysis
Decap Analysis & Placement
Impedance Analysis
Power Plane Noise Analysis
Power Plane Optimization
Tool: Mentor Hyperlynx® PI
Application Experience
ASIC Emulation (Xilinx)
ASIC Bring-up (Socket-based)
Processor boards
Functional Testing
Post Silicon Validation
​Customer Reference/Demo Designs
Certification / Compliance
End-Product
Die-on-Board
Firmware
Low-level / Bare metal coding
Bootloader porting
C / Python
Test code for bring-up
Support Client Firmware Teams
